Nap-Gard FBE Powder Coatings


Nap-Gard was developed to provide maximum corrosion protection of internal and external pipe for oil and gas pipelines as well as valve and girth weld coating protection.   Axalta Nap-Gard fusion bonded epoxy powder coatings are the innovator behind today’s pipe coating practices using epoxy coatings.

Available in single, dual and multi-layer systems, Nap-Gard is designed to provide maximum corrosion protection of internal and external pipe for oil and gas pipelines along with demanding wastewater and saltwater environments.

Nap-Gard also provides corrosion protection for:

  • Valve products
  • Rebar
  • Girth Welds



Nap-Gard External Pipe Coating

Single Layer Systems

7-2500 Series – In buried service, the coating is designed to be capable of withstanding continuous operating temperatures of 107°C (225°F). May also be used on the inside of steel pipe and fittings, and is NSF-61 approved for potable water services.

7-2514 EN Series – Designed to be capable of withstanding continuous operating temperatures of 103°C (217°F). Formulated to offer improved resistance to cathodic disbondment and excellent corrosion resistanceHigh Tg.

7-2555–  used in submerged or wet conditions where high in-service temperatures exist, up to 155°C (311°F)

Dual Layer Systems

7-2610- Abrasion resistant overcoat (ARO) provided abrasion an impact resitance, aids in protecting the the corrosion coating from damage during the installation or directional drilling process.

7-2504- Provides water and impact resistance at high temperatures, capable of withstanding continuous operating temperatures of 130°C (265°F).

7-2502NS- Provides a bonded, non-slip surface over standard FBE. This coating provides additional shear slip resistance to concrete coated pipe, used for negative buoyancy in offshore installations. (NS is a sacrificial coating and can be applied over any of our systems.

7-2675 – When used with 7-2555, the operating systems increases to 180°C (356°F). The second layer provides reduced water permeability and improved chemical resistance.



FBE Pipe Coating

7-0008- Capable of withstanding continuous operating temperatures of 93°C (200°F).

7-0017- Capable of withstanding continuous operating temperatures of 140°C (285°F). Provides corrosion protection in high temperature and high pressure sweet and sour gas environments.

7-0014 -Designed for both external and internal pipe coating for buried pipeline service.  In particular, it is recommended for use on the inside of steel pipe. Meets the requirements of AWWA standards C116, C213, C550 and CSA standard Z245.20-10. Certified to NSF-61, drinking water system components.



FBE Rebar

Nap-Gard functional coatings are a leading choice for rebar application for concrete structures and bridges. These systems meet or exceed the performance standards set by ASTM and AASHTO. They are designed to resist cobwebbing and shatter cracking when rebar is formed. These FBE Rebar systems are 100% solids, HAPs free, and are high building in just a single coat.



FBE Valve

7-4500 Coatings are designed for use as a valve coating. In testing, it meets the requirements of UL 262 Gate Valve specification and FM 1120/1130, 1510 and 1511 specifications. It has been certified to NSF-61, drinkingwater system components (AWWA C213).



Girth Weld Coating & FBE Repairs Materials

Axalta offers a two-part liquid epoxy material, FBE and epoxy patch compounds for repair of Nap-Gard coated pipe or rebar and for field joint coatings of external girth welds. Select systems are formulated to offer excellent cathodic disbondment performance for temperatures up to 150°C (302°F).

Technical Data Sheets


Type Title Date Filesize
Type Title Date Filesize

    Nap-Gard 7-2500 Series TDS.pdf
May 2, 2022
(PDF 210.8 kB)
May 2, 2022
(PDF 210.8 kB)

    Nap-Gard 7-0010 TDS.pdf
May 2, 2022
(PDF 532.6 kB)
May 2, 2022
(PDF 532.6 kB)

    Nap-Gard 7-0014 TDS.pdf
May 2, 2022
(PDF 786.5 kB)
May 2, 2022
(PDF 786.5 kB)

    Nap-Gard 7-0015 TDS.pdf
May 2, 2022
(PDF 207.9 kB)
May 2, 2022
(PDF 207.9 kB)

    Nap-Gard 7-0016 TDS.pdf
May 2, 2022
(PDF 602.5 kB)
May 2, 2022
(PDF 602.5 kB)

    Nap-Gard 7-2610 Series TDS .pdf
May 2, 2022
(PDF 581.6 kB)
May 2, 2022
(PDF 581.6 kB)

    Nap-Gard 7-2675 TDS.pdf
May 2, 2022
(PDF 231.0 kB)
May 2, 2022
(PDF 231.0 kB)

    Nap-Gard 7-2732P Series TDS.pdf
May 2, 2022
(PDF 162.1 kB)
May 2, 2022
(PDF 162.1 kB)

    Nap-Gard 7-2750 Series TDS.pdf
May 2, 2022
(PDF 222.7 kB)
May 2, 2022
(PDF 222.7 kB)

    Nap-Gard 7-2815FG TDS.pdf
May 2, 2022
(PDF 150.7 kB)
May 2, 2022
(PDF 150.7 kB)

    Nap-Gard 7-3500 TDS.pdf
May 2, 2022
(PDF 555.5 kB)
May 2, 2022
(PDF 555.5 kB)

    Nap-Gard 7-3500T TDS.pdf
May 2, 2022
(PDF 565.2 kB)
May 2, 2022
(PDF 565.2 kB)

    Nap-Gard 7-4500 TDS.pdf
May 2, 2022
(PDF 590.8 kB)
May 2, 2022
(PDF 590.8 kB)

    Nap-Gard 7-4510 TDS.pdf
May 2, 2022
(PDF 186.3 kB)
May 2, 2022
(PDF 186.3 kB)

    Nap-Gard 7-4527 TDS.pdf
May 2, 2022
(PDF 567.9 kB)
May 2, 2022
(PDF 567.9 kB)

    Sol-Gard PCW601S9 TDS.pdf
May 2, 2022
(PDF 453.0 kB)
May 2, 2022
(PDF 453.0 kB)

    Nap-Gard 7-0017HT TDS.pdf
May 2, 2022
(PDF 780.1 kB)
May 2, 2022
(PDF 780.1 kB)

    Nap-Gard 7-0017VHT TDS.pdf
May 2, 2022
(PDF 605.1 kB)
May 2, 2022
(PDF 605.1 kB)

    Nap-Gard 7-1631S TDS.pdf
May 2, 2022
(PDF 120.5 kB)
May 2, 2022
(PDF 120.5 kB)

    Nap-Gard 7-1677S TDS.pdf
May 2, 2022
(PDF 120.8 kB)
May 2, 2022
(PDF 120.8 kB)

    Nap-Gard 7-1808 TDS.pdf
May 2, 2022
(PDF 131.7 kB)
May 2, 2022
(PDF 131.7 kB)

    Nap-Gard 7-1854 TDS.pdf
May 2, 2022
(PDF 212.0 kB)
May 2, 2022
(PDF 212.0 kB)

    Nap-Gard 7-1861 TDS.pdf
May 2, 2022
(PDF 116.1 kB)
May 2, 2022
(PDF 116.1 kB)

    Nap-Gard 7-1862 TDS.pdf
May 2, 2022
(PDF 115.5 kB)
May 2, 2022
(PDF 115.5 kB)

    Nap-Gard 7-1868 TDS.pdf
May 2, 2022
(PDF 159.8 kB)
May 2, 2022
(PDF 159.8 kB)

    Nap-Gard 7-2502NS Series TDS.pdf
May 2, 2022
(PDF 557.2 kB)
May 2, 2022
(PDF 557.2 kB)

    Nap-Gard 7-2504 TDS.pdf
May 2, 2022
(PDF 591.0 kB)
May 2, 2022
(PDF 591.0 kB)

    Nap-Gard 7-2514EN Series TDS.pdf
May 2, 2022
(PDF 202.5 kB)
May 2, 2022
(PDF 202.5 kB)

    Nap-Gard 7-2525 TDS.pdf
May 2, 2022
(PDF 259.3 kB)
May 2, 2022
(PDF 259.3 kB)

    Nap-Gard 7-2534 TDS.pdf
May 2, 2022
(PDF 572.3 kB)
May 2, 2022
(PDF 572.3 kB)

    Nap-Gard 7-2540 TDS.pdf
May 2, 2022
(PDF 571.7 kB)
May 2, 2022
(PDF 571.7 kB)

    Nap-Gard 7-2555 TDS.pdf
May 2, 2022
(PDF 262.3 kB)
May 2, 2022
(PDF 262.3 kB)

Application Procedures


Type Title Date Filesize
Type Title Date Filesize

    7-0017 -Black_Beauty_FBE.PDF
Sep 12, 2018
(PDF 254.5 kB)
Sep 12, 2018
(PDF 254.5 kB)

    7-0010_Internal_Pipe_Coating.pdf
Sep 12, 2018
(PDF 255.6 kB)
Sep 12, 2018
(PDF 255.6 kB)

    7-0008__Internal_Pipe_Coating.pdf
Sep 12, 2018
(PDF 256.2 kB)
Sep 12, 2018
(PDF 256.2 kB)

    Nap-Gard 7-0016.pdf
Sep 12, 2018
(PDF 290.0 kB)
Sep 12, 2018
(PDF 290.0 kB)

    Nap-Gard_Field_Girth_Weld_FBE.PDF
Sep 12, 2018
(PDF 246.2 kB)
Sep 12, 2018
(PDF 246.2 kB)

    Nap-Gard_Gold_Dual.pdf
Sep 12, 2018
(PDF 327.2 kB)
Sep 12, 2018
(PDF 327.2 kB)

    Nap-Gard_Gold_Field_Girth_Weld.pdf
Sep 12, 2018
(PDF 247.0 kB)
Sep 12, 2018
(PDF 247.0 kB)

    7-1854-Spray Grade application procedure .pdf
Sep 12, 2018
(PDF 270.5 kB)
Sep 12, 2018
(PDF 270.5 kB)

    Nap-Gard 7-0017HT-VHT.pdf
Sep 12, 2018
(PDF 262.8 kB)
Sep 12, 2018
(PDF 262.8 kB)

    Nap-Gard_Nap-Rock_Field_Girth_Weld_FBE_Dual.pdf
Sep 12, 2018
(PDF 247.1 kB)
Sep 12, 2018
(PDF 247.1 kB)

    Nap-Gard_Non_Slip_Dual_Powder.pdf
Sep 12, 2018
(PDF 334.3 kB)
Sep 12, 2018
(PDF 334.3 kB)

    Na--Gard_Nap-Rock_Dual.pdf
Sep 12, 2018
(PDF 331.7 kB)
Sep 12, 2018
(PDF 331.7 kB)

Sep 12, 2018
(PDF 333.3 kB)

    Nap-Gard_Sol-Gard.pdf
Sep 12, 2018
(PDF 328.2 kB)
Sep 12, 2018
(PDF 328.2 kB)

    Nap-Gard_Single_Layer.pdf
Sep 12, 2018
(PDF 320.3 kB)
Sep 12, 2018
(PDF 320.3 kB)
